Description
Victron SmartSolar MPPT 250/60 with MC4 connectors: 60 A charge controller for 12, 24, 36 or 48 V batteries, up to 250 V PV input, with built-in Bluetooth for setup and monitoring in VictronConnect.
A solar charger gathers energy from your solar panels and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.
The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 V, provided the cells are not permanently sulphated or otherwise damaged.
Key features
- Ultra-fast MPPT tracking with up to 99% efficiency
- Rated charge current 60 A; PV open-circuit voltage up to 250 V
- Nominal PV power: 860 W at 12 V, 1,720 W at 24 V, 2,580 W at 36 V, 3,440 W at 48 V
- 12 / 24 / 48 V auto-select (36 V via VictronConnect)
- Two pairs of MC4 PV connectors, 30 A per MC4
- Bluetooth built in; VE.Direct port for GX device and VRM connection
- Multi-stage adaptive charge algorithm, fully adjustable
- Programmable relay and remote on/off terminal
- Up to 10 units synchronised over Bluetooth (VE.Smart Networking)
- 46 days of on-board history
Specifications
| Rated charge current | 60 A |
| Max. PV open-circuit voltage | 250 V |
| Max. PV short-circuit current | 35 A |
| Absorption / float (12 V) | 14.4 V / 13.8 V, adjustable |
| Battery terminals | Screw terminals, 35 mm² (2 AWG) |
| PV terminals | MC4 connectors, two pairs |
| Self-consumption | Less than 35 mA at 12 V, 20 mA at 48 V |
| Protection | IP43 electronics, IP22 connection area; PV reverse polarity, over-temperature, output short-circuit |
| Operating temperature | −30 °C to +60 °C |
| Safety | EN-IEC 62109-1, CSA C22.2, UL 1741 |
| Dimensions (h × w × d) | 215 × 250 × 95 mm |
| Weight | 3 kg |
| Warranty | 5 years |
Genuine Victron Energy product, part number SCC125060321. Euromotive Energy is an authorised Victron distributor for Ireland.
