Victron SHS 200 MPPT v3.0 MC4 – Solar Home System Charge Controller (12V)
The Victron SHS 200 MPPT v3.0 MC4 is a compact, rugged, and smart solar home system controller designed for powering lights, appliances, and small devices in off-grid environments. Built for long-term durability and ease of use, it combines MPPT solar charging with load control, system protection, and remote monitoring capabilities—making it perfect for rural electrification projects and developing markets.
Key Features:
-
Integrated MPPT Charge Controller:
Ensures maximum solar energy harvesting with ultra-fast tracking, even in low light or cloudy conditions. -
200W Solar Input Support:
Optimized for PV panels up to 200W at 12V, delivering consistent power to connected devices and battery banks. -
MC4 Solar Input Connectors:
Plug-and-play PV connection using industry-standard MC4 terminals—ideal for fast, tool-free installation. -
Smart Load Control:
Features two DC output channels with electronic short-circuit protection and programmable lighting modes. -
Bluetooth Monitoring:
Built-in Bluetooth lets users monitor and configure settings wirelessly using the VictronConnect app. -
Rugged Design for Harsh Environments:
Water- and dust-resistant enclosure with IP-rated connectors and internal fuse protection—designed for remote locations. -
Tamper-Proof & Prepayment Ready:
Supports integration with prepayment energy meters or token systems for commercial or NGO-led deployment models.
Technical Specifications:
-
System Voltage: 12V
-
Rated Charge Current: 15A
-
Max PV Power: 200W
-
PV Input Voltage: Max 100V open circuit
-
Battery Types: Lead-acid (GEL, AGM), Lithium (manual configuration)
-
Outputs: 2 DC loads (fused, programmable)
-
Monitoring: Bluetooth (VictronConnect) + optional remote monitoring via VRM
-
Enclosure: Compact IP-rated housing
-
Mounting: Wall or panel mount
Applications:
-
Off-grid homes and cabins
-
Rural solar electrification
-
NGO and development energy projects
-
Micro-utility and token-based solar systems
-
Remote agricultural and communication sites
📦 Includes: SHS 200 MPPT v3.0 MC4 unit with integrated terminal protection
