Description
The Victron MultiPlus-II 48/5000/70-95 120V 50/60Hz is a 5kVA inverter/charger for 48V battery systems with selectable 50 or 60Hz 120V AC output, for 120V installations worldwide. It combines a pure sine wave inverter, a 70A adaptive charger and a 95A transfer switch in one unit.
Key features
- 50/60Hz selectable: suits 120V systems in markets on either frequency.
- 95A transfer switch: passes through a large 120V supply to your loads.
- Uninterrupted power (UPS): takes over within milliseconds if the grid or generator drops out.
- PowerControl and PowerAssist: limits draw on a weak supply and boosts it with battery power during peak demand.
- Adaptive charging: suits lithium, AGM and gel batteries.
- Scalable and connected: parallel and split/three-phase capable; add a GX device for VRM remote monitoring.
Specifications
| Part number | PMP482505300 |
| Nominal battery voltage | 48V |
| AC output | 120VAC, 50/60Hz |
| Rated power | 5,000VA |
| Continuous output power | 4,000W at 25°C |
| Peak power | 9,000W |
| Max. battery charge current | 70A |
| Transfer switch | 95A |
| Communication | VE.Bus (2 x RJ45) |
| Dimensions (H x W x D) | 676 x 330 x 164 mm |
| Weight | 32 kg |
Note: this is a 120V model. For Irish and European 230V systems, see the MultiPlus-II 48/5000/70-50 230V.
