Description
The Victron Phoenix Inverter 48/1200 VE.Direct turns a 48V battery into clean 230V pure sine wave power for appliances, tools and electronics. It's a neat way to add a dedicated AC circuit to a 48V battery system, or to run AC loads from a 48V bank on a boat, truck or off-grid site. This version has an IEC-320 outlet, with a matching male IEC plug supplied.
Key features
- Pure sine wave output: safe for sensitive electronics.
- ECO mode: drops standby consumption when no load is connected.
- VE.Direct port: add a VE.Direct Bluetooth Smart dongle for setup and monitoring in VictronConnect, or connect to a GX device for VRM.
- Remote on/off: connector for a simple remote switch or the Inverter Control VE.Direct panel.
- Protected: against short circuit, overload, high/low battery voltage and over-temperature.
Specifications
| Part number | PIN482121100 |
| Nominal battery voltage | 48V |
| AC output | 230VAC, 50Hz pure sine wave |
| Rated power | 1,200VA |
| Outlet | IEC-320 (male IEC plug included) |
| Communication | VE.Direct |
| Dimensions (H x W x D) | 117 x 232 x 327 mm |
| Weight | 7.4 kg |
Genuine Victron Energy product. Euromotive Energy is an authorised Victron distributor for Ireland.
